UEA slip rings offer design versatility as component kit rings or as completed, ready-to-mount assemblies with optional pre-wired harnesses. A wide selection of circuitry is available with many combinations of amperage and voltage (AC or DC). The compact design is made possible by brushes stacked on alternating sides. UEA slip rings come in a variety of bore sizes, from .500” to 14.00”. Every order is custom designed for your specific motion application need. Our engineers work with you on the application to provide the highest performing quality slip ring available!

REQUEST A QUOTE ORDER NOW

How They Work

A slip ring is a rotary coupling used to transfer electric current from a stationary unit to a rotating unit. This is accomplished by either:

  • Holding the center core stationary while the brushes and housing rotate around it.
  • Holding the brushes and housing stationary while the center core is allowed to rotate

A wide selection of circuitry is available with many combinations of amperage and voltage (AC or DC). The compact design is made possible by brushes stacked on alternating sides.



Sizes and Samples

.500” - 1.00” Bore Slip Ring Ideal for small areas, limited number of circuits
1.5” Bore Slip Ring Most popular and versatile slip ring
2.5” - 4.00” Bore Slip Ring Unique design - Easily installed and serviced
6.00” - 8.00” Bore Slip Ring Designed for large center passageways
10.00" - 14.00” Bore Slip Ring Primarily used in large commercial and industrial applications

Case Studies

  • Slip Ring Reliability

    Slip Ring Reliability

    Read about a few helpful ideas for increasing the life of slip rings.

  • Irrigation Case Study

    Irrigation Case Study

    Bugs and condensation may be tiny, but they were causing big headaches for Reinke, a manufacturer of center pivot irrigation systems. The two pint-size problems were infiltrating the systems' collector reels, which at the time were made of steel.

  • Turning to a Better Answer

    Turning to a Better Answer

    Elliott Equipment, a manufacturer of cranes and related machinery, has been using slip rings from United Equipment Accessories (UEA) in its equipment for 23 years. When UEA started designing and manufacturing hydraulic swivels—a complementary part to the slip ring—in 2012, Elliott Equipment wanted to know more.
